Fully Automatic Desktop Flat Surface Labeling Machine | High Precision Top Label Applicator

Our fully automatic desktop flat labeling machine is a compact, high-efficiency solution for flat products, perfect for small and medium production lines and space-limited workshops. Made of SUS304 stainless steel and industrial parts, it achieves stable and precise labeling for boxes, lids, cards, cosmetic containers and other items.
Equipped with PLC system and intuitive touchscreen, it is easy to operate with little training. The modular structure allows upgrades like date coding units, delivering smooth, wrinkle-free labeling for food, pharmaceutical, electronic and other products.

• Food & Beverage: Plastic containers, takeout boxes, food trays, bottle caps
• Cosmetics: Jars, cream containers, perfume boxes, makeup palettes
• Pharmaceuticals: Medicine boxes, pill bottles, blister packs
• Electronics: Circuit boards, component boxes, mobile phone accessories
• Office & Stationery: Notebooks, folders, envelopes, business cards
• Logistics & Packaging: Cartons, shipping boxes, flat pouches

1. ±1mm High Precision: Photoelectric sensor + servo motor ensure ±1mm labeling accuracy (excluding product/label errors), no misaligned labels.
2. Compact & Space-Saving: Desktop design with integrated conveyor, easy to install/move, ideal for small production lines.
3. PLC Touchscreen Control: 7-inch color touchscreen with multi-language support, simple parameter setup and speed adjustment.
4. Wide Compatibility: Fits flat products (boxes, lids, cards, trays) and various pressure-sensitive labels (paper, film, transparent stickers).
5. SUS304 Durable Build: Stainless steel frame and conveyor, easy to clean and corrosion-resistant, suitable for food, pharma & cosmetics.
6. Safe & Low-Maintenance: Emergency stop, safety alerts, and modular parts for quick replacement & minimal downtime.
7. Flexible Upgrade Options: Compatible with inkjet/hot stamp date coders to print batch numbers, expiry dates, or barcodes on labels

Labeling Accuracy：                               ±1mm (without product/label error)
Labeling Speed：                                     30-120 pcs/min (depends on product size)
Applicable Product Size：                      Length: 20-300mm; Width: 20-200mm; Height: ≥5mm
Applicable Label Size：                          Width: 10-150mm; Length: 10-200mm
Conveyor Speed：                                    5-20m/min (adjustable)
Control System：                                     PLC + 7-inch color touchscreen
Drive System：                                         Stepper motor / Servo motor (optional)
Power Supply：                                        110V/220V 50/60Hz
Power Consumption：                            500W (standard)
Machine Material：                                 SUS304 stainless steel
Machine Dimension：                            L800×W400×H600mm (customizable)
Net Weight：                                            65kg
Working Environment Temperature:  5-40℃; Humidity: 15-85%RH (non-condensing)

Packaging:

By container or standard export packing per machine

Delivery Time:

15-30 days after payment received

Q: Are you manufacturer or trading Company?

A: We are manufacturer at Shanghai,China

Q: The machine is automatic or semi-auto?

A: We produce automatic machine & semi-auto machines

Q: Which kinds of machine suit for our products?

A: Pls supply your products all information ( product pictures and sizes, caper,label on it is rather helpful), then we will recommend the suitable machine for ref again.

Q: The machine can connect with the product line or not?

A: Machines connect with production line or operation alone all ok as you need .

Q: Whats our payment terms?

A: 50%advance by TT , 50% balance by TT before shipment after customer check well.

Q: How to ensure quality?

A: We will be responsible for any error, trouble and damage which cause of machine’s design, craftwork, manufacturing, installation, commissioning within warranty period.

Q: How long is our warranty?

A: Normally Other company provide one year maintenance,after warranty period, we still supply lifelong technical support and after-service. We will provide spare part which lost or damage because of us and in-time service.

Q: How to ensure our after-service?

A: If any request for after-service, customer can call our sales or send email , we will online at 24h at working days,we will ensure you prompt and serious reply at the first time.
