Product
The automatic double-sided labeling machine can attach labels on both sides at the same time, which is very useful for products that need to attach two different labels to the product or need double-sided labels, with high-speed operation capability, can quickly and accurately complete the label labeling task, suitable for large-scale production. Machines often have some adjustment flexibility to accommodate products or labels of different sizes and shapes. The operator can design the corresponding machine according to the size of the bottle.
Fully automatic double-sided labeling machine is a kind of equipment used to automatically attach labels on products or packaging. Such machines are often used on industrial production lines to improve production efficiency and ensure accurate label attaching. The following is the main description of the fully automatic double-sided labeling machine:
1. Automated operation: The fully automatic double-sided labeling machine is a highly automated equipment that can perform label attachment tasks without human intervention. It is often integrated with other equipment on the production line for a seamless production process.
2. Double-sided label attaching: This machine can attach two-sided labels at the same time, which is very useful for products that need to attach two different labels to the product or need double-sided labels.
3. High-speed operation: The automatic double-sided labeling machine usually has the ability to run at high speed, which can quickly and accurately complete the label attachment task, which is suitable for large-scale production.
4. Precise positioning: It uses a precise positioning system to ensure that labels are accurately attached to products or packaging. This typically involves the use of sensors, vision systems, or other technologies to detect the position and orientation of the product in order to attach a label in the correct position.
5. Adjustment flexibility: This kind of machine usually has some adjustment flexibility to adapt to different sizes and shapes of products or labels. The operator can adjust the machine’s settings as needed.
It is suitable for labeling the circumferential surface of round bottles. It can be used for single label and double label. The distance between the front and back double labels can be adjusted flexibly, such as labeling of gel water round bottles and food round cans. It is widely used in cosmetics, food. Disinfection water and other industries. The optional circumferential positioning detection device can realize labeling at the designated position on the circumferential surface.
Voltage: AC220V 50/60HZ
Power: 980W
Capacity: 120~250b/m（Adjustable speed, depending on object size and label length）
Accuracy: ±1mm（depends on object&label sizes and labeling pattern）
Bottle Diameter: 10~24mm
Bottle Height: L≤110mm~180mm（Can be customized）
Label Size: H10mm~80mm L15~80mm（Can be customized）
Size of Paper Roll: Inner diameter of label roll:Ф76mm；outer diameter of label roll:Ф300mm
Weight: 200kg
Dimension: 1850*1100*1300mm
Conveyor Width: Can be customized according to the diameter of the sample bottle.
Working principle:
Put the product on the conveyor belt and enter the bottle separating mechanism. After the bottle separating mechanism separates the product, the sensor detects the passing of the product and sends a signal back to the labeling control system. At the appropriate position, the control system controls the corresponding motor to send out the label and attach it to the product. At the position to be labeled, the label is covered at the same time, and the action of attaching a label is completed.
Operation process:
Put the product conveyor belt (can be connected to the assembly line)—>product conveying—>product separation—>product inspection—>product positioning—>labeling and relabeling—>collect labeled products
By container or standard export packing per machine
15-30 days after payment received.
Q: Are you manufacturer or trading Company?
A: We are manufacturer at Shanghai,China
Q: The machine is automatic or semi-auto?
A: We produce automatic machine & semi-auto machines
Q: Which kinds of machine suit for our products?
A: Pls supply your products all information ( product pictures and sizes, caper,label on it is rather helpful), then we will recommend the suitable machine for ref again.
Q: The machine can connect with the product line or not?
A: Machines connect with production line or operation alone all ok as you need .
Q: Whats our payment terms?
A: 50%advance by TT , 50% balance by TT before shipment after customer check well.
Q: How to ensure quality?
A: We will be responsible for any error, trouble and damage which cause of machine’s design, craftwork, manufacturing, installation, commissioning within warranty period.
Q: How long is our warranty?
A: Normally Other company provide one year maintenance,after warranty period, we still supply lifelong technical support and after-service. We will provide spare part which lost or damage because of us and in-time service.
Q: How to ensure our after-service?
A: If any request for after-service, customer can call our sales or send email , we will online at 24h at working days,we will ensure you prompt and serious reply at the first time.
