Fully Automatic Adhesive Tape Cutting Machine | High Precision Auto Tape Dispenser

Our AT-800 fully automatic adhesive tape cutting machine is a digital intelligent tape dispenser independently developed for mass production workshops. It solves the low efficiency, uneven cutting length and waste of manual tape cutting in electronic assembly, wire harness processing, new energy battery packaging and household appliance production lines.
Equipped with PLC digital control panel, users can set cutting length, cutting speed and cycle quantity with one key. The machine automatically feeds and cuts tape continuously without manual auxiliary pulling, supporting uninterrupted 24-hour industrial operation. It is compatible with almost all roll adhesives including double-sided tape, high-temperature masking tape, acetate cloth tape, fiberglass tape, electrical insulation tape, foam tape and protective film.
Built-in high-hardness alloy cutter, long service life and stable cutting tolerance within ±1mm. Adjustable tape width and thickness range to meet multi-spec production requirements. We provide 110V/220V dual voltage customization, CE & RoHS certification, 1-year whole machine warranty and lifetime spare parts supply, suitable for small factories and large automated production lines worldwide.

1. Digital PLC Intelligent Control
   Touch digital panel, 5–999mm adjustable cutting length in 1mm unit, memory storage of 9 groups of cutting parameters, one-click switching of different tape specifications.
2. Ultra-Stable Cutting Precision
   Imported alloy blade, cutting accuracy ±1mm, no burr, no stretching deformation of thin adhesive tapes, reduce raw material waste by over 30%.
3. Wide Compatibility for All Industrial Tapes
   Support tape width 6–60mm, tape thickness 0.05–0.5mm, max tape roll outer diameter 300mm, fit thin film tape to thick foam adhesive.
4. High-Speed Continuous Operation
   Feeding speed up to 220mm/s, maximum 50 cuts per minute, replace 3–4 manual workers, greatly improve workshop production efficiency.
5. Safe & Durable Industrial Structure
   Anti-jam feeding design, overload automatic power-off protection, ABS anti-static shell, low noise operation, adapt to long-time factory continuous work.
6. Global Voltage & Standard Certification
   Support 110V/220V 50/60Hz customized power supply, passed CE, RoHS certification, meet EU, Southeast Asia, North America production standards.

Control Mode：                              Digital PLC Control Panel
Cutting Length Range：                5mm – 999mm (1mm fine-tuning)
Available Tape Width：                 6mm – 60mm
Applicable Tape Thickness：        0.05mm – 0.5mm
Max Tape Roll Outer Diameter： 300mm
Cutting Precision：                          ±1mm
Feeding Speed：                               220mm/s
Max Cutting Frequency：               50 times/min
Working Power：                              60W
Input Voltage：                                 110V / 220V (Customizable)
Power Frequency：                           50Hz / 60Hz
Machine Dimension：                      260×155×130mm (L×W×H)
Net Weight：                                      2.6kg
Working Environment：                 -5℃ ~ 40℃, Humidity ≤80%RH
Certifications：                                  CE, RoHS

=

Packaging:

By container or standard export packing per machine

Delivery Time:

15-30 days after payment received

Q: Are you manufacturer or trading Company?

A: We are manufacturer at Shanghai,China

Q: The machine is automatic or semi-auto?

A: We produce automatic machine & semi-auto machines

Q: Which kinds of machine suit for our products?

A: Pls supply your products all information ( product pictures and sizes, caper,label on it is rather helpful), then we will recommend the suitable machine for ref again.

Q: The machine can connect with the product line or not?

A: Machines connect with production line or operation alone all ok as you need .

Q: Whats our payment terms?

A: 50%advance by TT , 50% balance by TT before shipment after customer check well.

Q: How to ensure quality?

A: We will be responsible for any error, trouble and damage which cause of machine’s design, craftwork, manufacturing, installation, commissioning within warranty period.

Q: How long is our warranty?

A: Normally Other company provide one year maintenance,after warranty period, we still supply lifelong technical support and after-service. We will provide spare part which lost or damage because of us and in-time service.

Q: How to ensure our after-service?

A: If any request for after-service, customer can call our sales or send email , we will online at 24h at working days,we will ensure you prompt and serious reply at the first time.
