Desktop Semi-Automatic Rotary Flat Labeling Machine, Servo Positioning Square & Flat Bottle Label Applicator

This desktop semi-automatic rotary flat labeling machine adopts servo rotary positioning mechanism, specially designed for flat-sided plastic jugs, square bottles, hand sanitizer containers and irregular flat packaging. Workers manually place the workpiece, the machine automatically completes positioning and labeling. Compared with full-automatic production lines, it occupies smaller space and has lower investment cost, ideal for small-batch production, new product trial and medium-sized packaging workshops. It can finish single-side flat labeling for daily chemical, pharmaceutical, electronic packaging products.

Servo Rotary Positioning System: Accurate rotation positioning, guarantee consistent labeling position for flat-sided containers
Compact Desktop Structure: Small footprint, suitable for laboratory, small workshop and pilot production line
Multi-Directional Adjustable Mechanism: X/Y/Z three-axis fine tuning for labeling head, flexible adaption for multiple product sizes
High Precision Photoelectric Label Sensor: Real-time label tracking, prevent empty labeling and label waste
High Strength Aluminum Alloy Frame: Lightweight, anti-deformation, easy to wipe and maintain
Simple Operation Mode: Manual feeding, automatic labeling, low learning cost for operators
Wide Label Compatibility: Support self-adhesive sticker labels, barcode labels, QR code labels, transparent film labels
Adjustable Label Roll Holder: Adapt various standard label rolls, convenient for label replacement

Machine Type: Desktop Semi-Automatic Rotary Flat Labeling Machine
Labeling Precision: ±0.8mm (exclude workpiece & label tolerance, conforms to GB/T 36519-2018)
Production Speed: 15–45 pieces per minute (depends on operator feeding speed)
Applicable Label Width: 10–160 mm
Applicable Flat Container Size: Length 40–220 mm, Width 30–150 mm
Control Mode: Servo motor + PLC control
Power Supply: AC110V/220V 50/60Hz
Rated Power: 0.45 KW
Main Machine Material: High-strength industrial aluminum alloy
Max Label Roll Outer Diameter: 280 mm
Working Air Pressure: 0.4–0.6 MPa (need air compressor)
Machine Overall Dimension (LWH): 780450620 mm
Net Weight: 85 KG

Packaging:

By container or standard export packing per machine

Delivery Time:

15-30 days after payment received

Q: Are you manufacturer or trading Company?

A: We are manufacturer at Shanghai,China

Q: The machine is automatic or semi-auto?

A: We produce automatic machine & semi-auto machines

Q: Which kinds of machine suit for our products?

A: Pls supply your products all information ( product pictures and sizes, caper,label on it is rather helpful), then we will recommend the suitable machine for ref again.

Q: The machine can connect with the product line or not?

A: Machines connect with production line or operation alone all ok as you need .

Q: Whats our payment terms?

A: 50%advance by TT , 50% balance by TT before shipment after customer check well.

Q: How to ensure quality?

A: We will be responsible for any error, trouble and damage which cause of machine’s design, craftwork, manufacturing, installation, commissioning within warranty period.

Q: How long is our warranty?

A: Normally Other company provide one year maintenance,after warranty period, we still supply lifelong technical support and after-service. We will provide spare part which lost or damage because of us and in-time service.

Q: How to ensure our after-service?

A: If any request for after-service, customer can call our sales or send email , we will online at 24h at working days,we will ensure you prompt and serious reply at the first time.
