Product
This machine apply to round, conical objects such as cups, tubes, cans, boxes, bottles, barrels, etc. in food, medical, cosmetics, electronics, plastics, toys, hardware, auto parts, stationery, etc. Dry adhesive labels, self-adhesive films, electronic supervision codes, bar codes, etc. Labeling on the circumferential surface, conical surface and four aspects of the product.
This machine adopt to stick Self-adhesive labels, self-adhesive films, electronic supervision codes, bar codes on round cups, tubes, cans, boxes, bottles, barrels and other round, conical objects of food, medical, cosmetics, electronics, plastics, toys, hardware, auto parts, stationery, etc. Labeling on the circumferential surface, conical surface and four aspects of the product (products that can be transported upright)；
Improve product labeling, film attachment efficiency, accurate attachment position, good quality and high stability; avoid manual labeling, low film efficiency, skewing, blistering and wrinkling, irregular placement, etc. A series of problems; effectively reduce product costs, improve product logo aesthetics, and enhance product competitiveness；
1.The main material of the equipment is stainless steel and high-grade aluminum alloy. The overall structure is firm and beautiful. The whole machine adopts imported control system and operating system. The attachment position is accurate, the quality is good, the stability is high, the operation is convenient, and the adjustment part is convenient and simple.
2.Ingenious design of structural adjustment part and label winding of mechanical adjustment part, fine adjustment of degree of freedom of labeling position (fixable after adjustment), making conversion and label winding between different products simple and time-saving;
3.The adjustment range is relatively wide, and can be adjusted according to the product within the specified range. It has no object and no labeling, no standard automatic calibration and automatic detection function;
4.Complete equipment supporting materials (including equipment structure, principle, operation, maintenance, maintenance, upgrade, etc.) to provide sufficient protection for the normal operation of the equipment;
5.With fault alarm function, production counting function, power saving function, production number setting prompt function, parameter setting protection function;
6.Operation process: release product – product delivery (automatic realization of equipment) -labeling (automatic realization of equipment) – collect the labeled products.
Machine Model:LB-100
Product size:Φ20≤D≤Φ150mm,H≤150mm
Label size:L≥20mm,15≤W≤200mm
Labeling precision:±1mm (exclude product&label error)
Labeling speed:30-150 B/M（related to product&label size）
Power Supply:220V，50/60Hz, 1.2KW
Machine Size:2000*1200*1300mm3
Machine Weight:260kg
