KX-10A Case Erector Machinery

Machine Description

automatic carton erector can open carton, shape, fold and stick the adhesive tape automatically. Our case erector can automatically correct the right-angle. Automatic carton erector is widely used in automatic packing line, it can continue opening carton in mass quantity, fold the bottom and sealing automatically. Equipped PLC and touch screen control, convenient for operation and management, it helps save large manpower.

And according to client’s requirement, automatic carton erector can be equipped hot melt glue machine for sealing.


Machine Feature

1 Imported parts, electrical and pneumatic components;

2 Automatically adjust the height and the width for different size of cartons;

3 Advanced pneumatic control system compare with the complicated electrical control system;

4 Fold the top covers automatically, side belts driven top and bottom sealing;

5 Cutter Safety system to prevent hands form stabbed by the cutter;

6 Both steel and stainless steel types.

7 Photoelectricity induction system

Technical Parameter


Packing Speed: 25 ctns/min

Carton Storage Quantity: 100pcs(1000mm)

Carton Size:  L+W≤900mm; W≤400mm; H+1/2W

Applicable Tape: 48mm, 60mm, 75mm (Choose one type)

Supply Power: 2kw

Machine Size:  L2580×W1150×H1800mm

Machine Weight:990kg
